32BDL4550D/00

32BDL4550D/00
Size
  • 32

Amaze your guests with a smarter, faster, signage display. With integrated WiFi and designed for running Android apps, it's the next evolution in signage solutions.

Designed to enhance

Philips_Product_Video_D-Modularity_20230905_NoText_Still_03

Public venues

Inform and engage visitors in public spaces. The D-Line features an IntegratedSystem to communicate with devices over the same wireless connectivity. FailOver ensures that backup content is played if the primary source experiences an outage.

Philips_Product_Video_D-Modularity_20230905_NoText_Still_01

Retail

Optimise any retail space for a better shopping experience. Easily create and control promotional content across single or multiple displays with PPDS Wave, and ensure content is always playing in case of primary source outages with FailOver.

KV-corporate_image_blank-1

Corporate

Easily connect and share content for ultra-efficient meetings and presentations. Built-in Android and SmartBrowser provide access to more apps, media content and devices, whilst CMND allows for updateable internal communications in an instant.

D-Line_Food and Beverage_Cafe

Food & beverage

Easily display menus, update item availability, pricing, and promotions with CMND. Integrated SmartPlayer and internal MemoryCache allow for local content scheduling, whilst FailOver ensures backup content is always available.

D-Line_transportation_airport

Transportation

Instantly update arrivals, departures and important announcements with ease using CMND. Built-in Android allows for live information and custom software integration from apps, whilst FailOver displays backup transport information in case of a primary source outage.

Entertainment

Wow patrons with a screen size up to 98-inches. CMND allows for quick content updates across single or multiple displays, whilst internal MemoryCache and FailOver ensure that content is always running.

D-LINE

Bigger impact

Proof of Play

Be sure your Android-powered Philips professional display is showing the right content-even when you're not there. When playing content via the embedded media player, you can set up your display to take automatic screenshots at regular intervals. Screenshots are stored on the display's internal memory, and you can choose to receive them via email.

22 Android Hospitality Hotel Reception

Powered by Android

Android-powered Philips professional displays are fast, versatile and easy to navigate. All displays are optimised for native Android apps and you can install web apps directly to the display too. Automatic updates ensure apps stay up to date.

TRANSPORT - Airport Departures

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips professional display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

14-Lobby-Reception-B-philips-b-line

Smart Power

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

CMND

Take control of your Philips Professional Display network. CMND lets you manage, update, maintain and play via one easy-to-use interface. From installation to daily operation.

CMND & Create

Take control of your content with CMND and Create. A drag-and-drop interface makes it simple to publish your own content, whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure that your stills, text and video will be up and running in no time.

07 Q-Line Transport Departures Lounge

Internal memory

Save and play content without the need for a permanent external player. Your Philips professional display has an internal memory, which allows you to upload media into the display for instant playback. The internal memory also functions as a cache for online streaming.

Q-Line 43BDL3010Q Image

Integrated HTML5 browser

Connect and control your content over the internet with the integrated HTML5 browser. Using the Chromium-based browser, design your content online and connect a single display or your complete network. Show content in both landscape and portrait mode, with full-HD resolution. Streaming content can also be shown in a PIP (picture-in-picture) window. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlist

01 D-Line Public Venue Aquarium

ADS wide-view panel display

Be seen from any angle with ADS wide-view technology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy and superior colour reproduction with 180 degree viewing.

Made for results

Picture/Display
Diagonal screen size (metric) 81.28
Diagonal screen size (inch) 32
Panel resolution 1920 x 1080p
Optimum resolution 1920 x 1080 @ 60 Hz
Brightness 400
Contrast ratio (typical) 1200:1
Dynamic contrast ratio 500,000:1
Aspect ratio 16:9
Response time (typical) 8
Pixel pitch 0.36375 (H) x 0.36375 (V) mm
Display colours 16.7 Million
Viewing angle (horizontal) 178
Viewing angle (vertical) 178
Picture enhancement 3/2 - 2/2 motion pull down
3D Combfilter
Motion compens. deinterlacing
3D MA deinterlacing
Dynamic contrast enhancement
Progressive scan
Operating system Android 8.0
Panel technology IPS
Connectivity
Video input Display Port1.2 (x 1)
DVI-I (x 1)
HDMI 2.0 (x 2)
USB 2.0 (x 2)
Audio input 3.5 mm jack
Audio output 3.5 mm jack
Video output DisplayPort 1.2 (x 1)
HDMI 2.0 (x 1)
External control RS232C (in/out) 2.5 mm jack
RJ45
IR (in/out) 3.5 mm jack
Supported Display Resolution
Computer formats 1920 x 1080, 60 Hz
1024 x 768, 60 Hz
1280 x 1024, 60 Hz
1280 x 720, 60 Hz
1440 x 900, 60 Hz
1600 x 900, 60 Hz
1680 x 1050, 60 Hz
640 x 480, 60 Hz
800 x 600, 60 Hz
Video formats 1080i, 50, 60 Hz
576i, 50 Hz
 576p, 50 Hz
480p, 60 Hz
480i, 60 Hz
1080p, 50, 60 Hz
720p, 50,60 Hz
Dimensions
Set Width 726.5
Set Height 425.4
Set Depth 65.1 (@Wall mount)/ 69.1 (@AC)
Set Width (inch) 28.60
Set Height (inch) 16.75
Set Depth (inch) 2.56 inch (@Wall mount) /2.72 (@AC))
Bezel width 11.9 mm (T/R/L), 17.2 mm (B)
Product weight 5.7
Product weight (lb) 12.57
Wall Mount 100 (H) x 100 (V) mm / 200 (H) x 200 (V) mm,
M4
Convenience
Placement Landscape (24/7)
Portrait (24/7)
Tiled Matrix Up to 10 x 15
Keyboard control Hidden
Lockable
Signal loop through DisplayPort
RS232
HDMI
IR Loop through
Network controllable RS232
Energy-saving functions Smart Power
Screen-saving functions Pixel Shift, Low Bright
WiFi protocol a b g n, 802.1x
Power
Consumption (Typical) 44
Consumption (Max) 85 W
Standby power consumption <0.5 W
Mains power 100 ~ 240 VAC, 50 ~ 60 Hz
Energy Label Class G
Operating conditions
Temperature range (operation) 0 ~ 40
Temperature range (storage) -20 ~ 60
Altitude 0 ~ 3000 m
MTBF 50,000
Humidity range (operation)[RH] 20–80% RH (No condensation)
Humidity range (storage) [RH] 5–95% RH (No condensation)
Sound
Built-in speakers 2 x 10 W RMS
Accessories
Stand BM05911 (Optional)
Included accessories Quick start guide
RS232 cable
AC Power Cord
IR sensor cable (1.8 M)
Remote Control and AAA Batteries
Included Accessories RS232 daisy-chain cable
Philips logo (x 1)
USB Cover (x 1)
Screws
Multimedia Applications
USB Playback Video H.263
H.264
H.265
USB Playback Picture BMP
JPEG
PNG
USB Playback Audio MPEG
H.263
H.264
H.265
Miscellaneous
On-Screen Display Languages English
French
German
Spanish
Polish
Turkish
Russian
Italian
Simplified Chinese
Traditional Chinese
Arabic
Japanese
Danish
Dutch
Finnish
Norwegian
Portuguese
Swedish
Regulatory approvals CE
CCC
RoHS
BSMI
CB
VCCI
CU
EMF
EnergyStar 8.0
ETL
FCC, Class A
PSB
Warranty 3 year warranty
Internal Player
CPU 2 x A53 + 2 x A73
GPU ARM Mali G51
Memory 3 GB DDR
Storage 32 GB eMMc
The following are product notes:
1. Before using the product, please carefully read the manual in the accessory box and keep it for future reference.
2. Please use the power cord and accessories provided with the product.
3. Do not bend, twist or pull the power cord forcibly.
4. For the installation method, please follow the "Wall Mounting Installation Instructions" in the wall mounting bracket for installation.
5. If the product is not used for a long time, please turn off the power and remove the plug.
6. In order to avoid fogging of the product, please put the product in the same space (without power on) for 1 to 2 hours, let the temperature/humidity of the product be close to the temperature/humidity of the space before turning on the product.
