65BDL4550D/00

65BDL4550D/00
Size
  • 65

Amaze your guests with a smarter, faster signage display. With integrated WiFi and designed for running Android apps, it's the next evolution in signage solutions

D-LINE

Bigger impact

Internal memory

Save and play content without the need for a permanent external player. Your Philips professional display has an internal memory, which allows you to upload media into the display for instant playback. The internal memory also functions as a cache for online streaming.

22 Android Hospitality Hotel Reception

Powered by Android

Android-powered Philips professional displays are fast, versatile and easy to navigate. All displays are optimised for native Android apps and you can install web apps directly to the display too. Automatic updates ensure apps stay up to date.

Proof of Play

Be sure your Android-powered Philips professional display is showing the right content-even when you're not there. When playing content via the embedded media player, you can set up your display to take automatic screenshots at regular intervals. Screenshots are stored on the display's internal memory, and you can choose to receive them via email.

TRANSPORT - Airport Departures

FailOver

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips professional display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

Smart Power

The backlight intensity can be controlled and pre-set by the system to reduce the power consumption by up to 50%, which saves substantially on energy costs.

CMND

Take control of your Philips Professional Display network. CMND lets you manage, update, maintain and play via one easy-to-use interface. From installation to daily operation.

CMND & Create

Take control of your content with CMND and Create. A drag-and-drop interface makes it simple to publish your own content, whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure that your stills, text and video will be up and running in no time.

CMND_Room_V2_FINAL

CMND & Control

Run your display network over a local (LAN or RF) connection. CMND & Control allows you to perform vital functions like updating software and settings, as well as monitoring display status. Whether you’re in charge of one display or more, CMND & Control makes managing your fleet easy.

Q-Line 43BDL3010Q Image

Integrated HTML5 browser

Connect and control your content over the internet with the integrated HTML5 browser. Using the Chromium-based browser, design your content online and connect a single display or your complete network. Show content in both landscape and portrait mode, with full-HD resolution. Streaming content can also be shown in a PIP (picture-in-picture) window. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlist

01 D-Line Public Venue Aquarium

ADS wide-view panel display

Be seen from any angle with ADS wide-view technology. Advanced Super Dimension Switch delivers faster on-display picture processing for smoother content transitions, remarkable image accuracy and superior colour reproduction with 180 degree viewing.

Automatic screenshots

Content is king, and with the automatic screenshot feature, you can make sure that your content is up and running at all times. Screenshots are taken throughout the day, which are then stored in the FTP server. From there, the screenshots can be viewed no matter when, or where you are.

Made for results

Picture/Display
Diagonal screen size (metric) 163.8
Diagonal screen size (inch) 64.5
Panel resolution 3840 x 2160
Optimum resolution 3840 x 2160 @ 60 Hz
Brightness 500
Contrast ratio (typical) 1200:1
Dynamic contrast ratio 500,000:1
Aspect ratio 16:9
Response time (typical) 8
Pixel pitch 0.372 x 0.3 72 mm
Display colours 1.07 G Billion
Viewing angle (horizontal) 178
Viewing angle (vertical) 178
Picture enhancement 3/2 - 2/2 motion pull down
3D Combfilter
3D MA deinterlacing
Dynamic contrast enhancement
Motion compens. deinterlacing
Progressive scan
Operating system Android 8.0
Panel technology ADS
Connectivity
Video input Display Port1.2 (x 1)
DVI-I (x 1)
HDMI 2.0 (x 3)
USB 2.0 (x 2)
Audio input 3.5 mm jack
Audio output 3.5 mm jack
Video output DisplayPort 1.2 (x 1)
HDMI 2.0 (x 1)
External control RJ45
RS232C (in/out) 2.5 mm jack
IR (in/out) 3.5 mm jack
Other connections OPS
Wi-Fi dual aerial 2,4Ghz and 5Ghz
4G/LTE antenna connectors mPCIe
Supported Display Resolution
Computer formats 1920 x 1080, 60 Hz
1680 x 1050, 60 Hz
1600 x 900, 60 Hz
1024 x 768, 60 Hz
1280 x 1024, 60 Hz
1280 x 720, 60 Hz
1440 x 900, 60 Hz
3840 x 2160, 30, 60 Hz
640 x 480, 60 Hz
800 x 600, 60 Hz
Video formats 1080i, 50, 60 Hz
576p, 50 Hz
576i, 50 Hz
480p, 60 Hz
480i, 60 Hz
1080p, 50, 60 Hz
2160p, 24, 30, 60 Hz
720p, 50,60 Hz
Dimensions
Set Width 1462.3
Set Height 837.3
Set Depth 89.9 (D@Handle)/ 68.9 (D@Wall mount)
Set Width (inch) 57.57
Set Height (inch) 32.96
Set Depth (inch) 3.54 (D@Handle)/ 2.71 (D@Wall mount)
Bezel width 14.9 mm (Even bezel)
Wall Mount 400 (H) x 400 (V) mm
M8
Product weight 28.1
Product weight (lb) 61.95
Convenience
Placement Landscape (24/7)
Portrait (24/7)
Tiled Matrix Up to 10 x 15
Keyboard control Hidden
Lockable
Signal loop through IR Loop through
DisplayPort
HDMI
RS232
Network controllable RS232
Energy-saving functions Smart Power
Screen-saving functions Pixel Shift, Low Bright
WiFi protocol a b g n, 802.1x
Power
Standby power consumption <0.5 W
Mains power 100 ~ 240 VAC, 50 ~ 60 Hz
Consumption (Typical) 179
Consumption (Max) 309 W
Energy Label Class G
Operating conditions
Temperature range (operation) 0 ~ 40
Temperature range (storage) -20 ~ 60
Altitude 0 ~ 3000 m
MTBF 50,000
Humidity range (operation)[RH] 20–80% RH (No condensation)
Humidity range (storage) [RH] 5–95% RH (No condensation)
Sound
Built-in speakers 2 x 10 W RMS
Accessories
Included Accessories AC Power Cord
RS232 cable
Quick start guide
IR sensor cable (1.8 M)
Remote Control and AAA Batteries
RS232 daisy-chain cable
Philips logo (x 1)
AC Switch Cover
USB Cover (x 1)
Screws
Multimedia Applications
USB Playback Audio AAC
HEAAC
MPEG
USB Playback Picture BMP
JPEG
PNG
USB Playback Video MPEG
H.263
H.264
H.265
Miscellaneous
On-Screen Display Languages English
French
German
Spanish
Polish
Turkish
Russian
Italian
Simplified Chinese
Traditional Chinese
Arabic
Japanese
Danish
Dutch
Finnish
Norwegian
Portuguese
Swedish
Regulatory approvals CB
CE
BSMI
CCC
FCC, Class A
PSB
RoHS
VCCI
CU
EMF
EnergyStar 8.0
ETL
Warranty 3 year warranty
Internal Player
CPU 2 x A53 + 2 x A73
GPU ARM Mali G51
Storage 32 GB eMMc
Memory 3 GB DDR
The following are product notes:
1. Before using the product, please carefully read the manual in the accessory box and keep it for future reference.
2. Please use the power cord and accessories provided with the product.
3. Do not bend, twist or pull the power cord forcibly.
4. For the installation method, please follow the "Wall Mounting Installation Instructions" in the wall mounting bracket for installation.
5. If the product is not used for a long time, please turn off the power and remove the plug.
6. In order to avoid fogging of the product, please put the product in the same space (without power on) for 1 to 2 hours, let the temperature/humidity of the product be close to the temperature/humidity of the space before turning on the product.
