55BDL3452T/00

Size

Inspire collaboration. Deliver information. This responsive Philips Multi-Touch Professional UHD Display is ideal for multi-finger, multi-user applications—from wayfinding to presentations. Up to 20 touch points can be active at once.

On-line introduce Arrange a ues

Education

Set a higher benchmark and lead a smarter classroom. The brilliantly designed T-Line boasts an anti-glare and anti-reflection 4K screen to ensure that your content is always the focal point in any lighting condition. It’s equally as impressive on the inside, with a plethora of features that will enable students to design, invent, collaborate and translate their ideas for the real world.

Corporate

Bring greater engagement to your workspace - in the boardroom, meeting rooms and beyond. The The Philips T-Line includes an interactive white board, video conferencing and more to enable colleagues to present and collaborate with confidence.

T-LINE

Collaborate with confidence

Wireless screen sharing

Display four feeds on the one screen. Wireless screen sharing allows you to connect up to 64 devices at the same time for quick content switching when you need it. Use your existing Wi-Fi network to instantly and securely connect devices, or the Interact dongle to connect guest speakers and remote access students logged in using an external network.

CMND & Control

Take control of your content with CMND and Create. A drag-and-drop interface makes it simple to publish your own content, whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure that your stills, text and video will be up and running in no time.

CMND & Create

Infrared Touch with USB Plug-and-Play

Experience a better way to control content. Simply plug your existing laptop or desktop to enable touch functionality on the big screen instantly. USB plug-and-play means that no installations or configuration is required, with options to plug removable devices from the side or having them fixed from the back.

Whiteboard mode

Inspire agile collaboration with whiteboard mode. Simply activate this feature to turn your display into a blank canvas that can be drawn on by multiple users by hand or with dedicated display markers. Everything on screen can then be streamed back to your laptop for easy printing or file sharing.

Video conferencing

Built-in video conferencing makes video calls with single or multiple people quick, reliable and easy. Simply connect a compatible camera and use the included software, or connect via third party apps such as Skype, Zoom and others to make your calls.

Made for results

Picture/Display
Diagonal screen size (metric)	138.8
Diagonal screen size (inch)	55
Panel resolution	3840 x 2160
Optimum resolution	3840 x 2160
Optimum resolution	3840 x 2160 @ 60 Hz
Brightness	400
Contrast ratio (typical)	1300:1
Surface treatment	Anti-Glare coating
Aspect ratio	16:9
Response time (typical)	8
Pixel pitch	0.315 (H) x 0.315 (V) mm
Display colours	1.07 B
Viewing angle (horizontal)	178
Viewing angle (vertical)	178
Picture enhancement	3/2 - 2/2 motion pull down
	3D Combfilter
	Motion compens. deinterlacing
	Progressive scan
	3D MA deinterlacing
	Dynamic contrast enhancement
Panel technology	IPS
Operating system	Android 8.0
Interactivity
Multi-touch technology	IRHE
Touch points	20 simultaneous touch points
Plug and play	HID compliant
Protection glass	3 mm tempered safety glass
Connectivity
Video input	DVI-D (x 1)
	HDMI 2.0 (x 2)
	USB 2.0 Type A (x 2)
	USB 2.0 Type B (x 1)
	VGA (Analogue D-Sub) (x 1)
Audio input	3.5 mm mini jack (x 1)
Audio output	3.5 mm Mini Jack (x 1)
External control	RJ45
	IR (in/out) 3.5 mm jack
	RS232C (in/out) 2.5 mm jack
Other connections	OPS
Other connections	micro SD
Supported Display Resolution
Computer formats	640 x 480, 60, 67, 72, 75 Hz
	800 x 600, 56, 60, 72, 75 Hz
	1024 x 768, 60 Hz
	1280 x 768, 60 Hz
	1280 x 800, 60 Hz
	1280 x 1024, 60 Hz
	1360 x 768, 60 Hz
	1366 x 768, 60 Hz
	1440 x 900, 60 Hz
	1600 x 1200, 60 Hz
	1920 x 1080, 60 Hz
	1920 x 1200, 60 Hz
	720 x 400, 70 Hz
	800 x 600, 60, 72, 75 Hz
	3840 x 2160, 60 Hz, 50 Hz
Video formats	480i, 60 Hz
	480p, 60 Hz
	576p, 50 Hz
	576i, 50 Hz
	720p, 50, 60 Hz
	1080i, 50, 60 Hz
	1080p, 50, 60 Hz
	1080i, 25, 30 Hz
	480i, 30, 60 Hz
	576i, 25, 50 Hz
	3840 x 2160, 24, 25 Hz
	3840 x 2160, 30Hz
Convenience
Placement	Landscape (18/7)
Placement	Portrait (18/7)
Signal loop through	IR Loop through
Signal loop through	RS232
Network controllable	RS232
Network controllable	RJ45
Keyboard control	Hidden
Keyboard control	Lockable
Screen-saving functions	Pixel Shift, Low Brightness
Remote control signal	Lockable
Energy-saving functions	Smart Power
Dimensions
Set Width	1272.6
Set Height	743.4
Set Depth	75.5 (D@Wall mount)/81.7 (D@OPS Cover)
Set Width (inch)	50.10
Set Height (inch)	29.27
Set Depth (inch)	2.97 (D@Wall mount)/3.22 (D@OPS Cover)
Bezel width	16.3 mm (T/R/L/B)
Product weight	27.0
Product weight (lb)	59.52
Wall Mount	400 x 400 mm
Wall Mount	M6
Sound
Built-in speakers	2 x 10 W
Operating conditions
Temperature range (operation)	0 ~ 40
MTBF	50,000
Altitude	0 ~ 3000 m
Temperature range (storage)	-20~60
Humidity range (operation)[RH]	20–80% (without condensation)
Humidity range (storage) [RH]	5–95% (without condensation)
Power
Mains power	100 ~ 240 VAC, 50/60 Hz
Standby power consumption	<0.5 W
Consumption (Typical)	140
Power Saving Features	Smart Power
Consumption (Max)	270 W
Energy Label Class	G
Accessories
Included Accessories	Cleaning cloth (x 1)
	IR sensor cable (1.8 m) (x 1)
	Philips logo (x 1)
	Power supply cable (3 m)
	Quick start guide (x 1)
	RS232 daisy-chain cable
	Remote control and AAA batteries
	RS232 cable (3 m) (x 1)
	RS232 daisy chain cable (x 1)
	USB Cover and screw x 1
Stand	BM05922 (Optional)
Miscellaneous
On-Screen Display Languages	Arabic
	English
	French
	German
	Italian
	Japanese
	Polish
	Spanish
	Turkish
	Russian
	Simplified Chinese
	Traditional Chinese
	Danish
	Dutch
	Finnish
	Norwegian
	Portuguese
	Swedish
Regulatory approvals	BSMI
	CB
	CE
	FCC, Class A
	RoHS
	CU
	ETL
	IMDA
	PSB
Warranty	3 year warranty
Multimedia Applications
USB Playback Picture	BMP
	GIF
	JPEG
	JPG
	PDF
USB Playback Audio	AAC
	AIF
	AIFF
	ASF
	LPCM
	M3U
	M4A
	MP3
	MP4
	WAV
	WMA
USB Playback Video	M2TS
	M4V
	MK3D
	MKV
	MP4
	MPEG
	MPG
	MTS
	TS
	TTS
	VOB
	WMV
Internal Player
CPU	2 x A53 + 2 x A73
Memory	2 GB DDR3/8 GB
GPU	ARM Mali G51
Wi-Fi	2.4 G
Wi-Fi	5 G

The following are product notes:
1. Before using the product, please carefully read the manual in the accessory box and keep it for future reference.
2. Please use the power cord and accessories provided with the product.
3. Do not bend, twist or pull the power cord forcibly.
4. For the installation method, please follow the "Wall Mounting Installation Instructions" in the wall mounting bracket for installation.
5. If the product is not used for a long time, please turn off the power and remove the plug.
6. In order to avoid fogging of the product, please put the product in the same space (without power on) for 1 to 2 hours, let the temperature/humidity of the product be close to the temperature/humidity of the space before turning on the product.
